Cervelo ZFS-5 GX AXS

Cervelo ZFS-5 GX AXS
Color: Five Black
Size: Select size
Please select options Unavailable
Order now and pick up in-store for free


Progressive but racy, ZFS-5 was built for today's evolving XCO courses-it has to pedal well and handle quickly, but also take on the chunks, jumps, and drops littering the circuit. ZFS-5's 67.8-degree head tube angle delivers the precision required for elbow-to-elbow hole shot sprints, and the confidence to let off the brakes when the track gets rough. And in 120mm-outfitting, the 66.6-degree head angle will give you the extra confidence to push harder and ride faster, even when the trail gets a bit...hellish.

- Flat Bars, Suspension, Cervelo?
World Cup season is here, and we're all in. The Z bikes—the ZHT-5 and the ZFS-5, our hardtail, and full-suspension, respectively—made their race debut at the Nove Mesto World Cup. The pilots? World Cup veteran and former Dutch National XCO Champion Milan Vader alongside reigning Cyclocross World Champion Fem van Empel.

- Call It A Comeback
Milan Vader is a veteran XC racer and former Dutch National Champion. He was set to race the Z bikes in 2022, but a life-changing crash at Itzulia Basque Country meant his priorities were re-learning to walk and ride. He's recovered phenomenally well and much faster than the doctors expected and will be racing the entire World Cup circuit this year.

- Double Dutch
Fem van Empel is one of Team Jumbo-Visma's most recent signings, and she's already made the rainbow connection. Following a decisive World Cyclocross Championships win in Hoogerheide, she traded knobbies for slicks this Spring and has now set her sights on improving her best-ever World Cup results and landing on the podium.

Frame SizeSmallMediumLargeX-Large
Reach | mm 421 445 469 496
Stack | mm 584 590 601 614
Head Tube Angle 67.8° 67.8° 67.8° 67.8°
Front Center | mm 692 718 746 779
Bottom Bracket Drop | mm 42 42 42 42
Head Tube Length | mm 96 102 114 128
Top Tube Length | mm 561.6 589.1 617.3 649.1
Seat Tube Angle 76.5° 76.3° 76.2° 76°
Standover Height | mm 746 744 744 744
Wheel Size 29 29 29 29
Fork Offset | mm 44 44 44 44
Wheelbase | mm 1120 1149 1180 1215
Chainstay Length | mm 432 435 437 440
Frame SizeRider Height (cm)Rider Height (in)
Small 154 - 165 5'0" - 5'4"
Medium 165 - 176 5'4" - 5'9"
Large 176 - 186 5'9" - 6'1"
X-Large 186 - 200 6'1" - 6'7"


Fork Rockshox SID SL Select+, DebonAir spring, 3 position remote Charger Race Day damper, tapered steerer, 15x110mm, Maxle Stealth, 44mm offset, 100mm
Rear Shock Rockshox SIDLuxe Select+, RL 3 position remote damper, 190 x 40mm
Wheels Front: Race Face ARC Offset 27, 27mm IW, DT Swiss 370, 15x110mm, 24H, 6 bolt, tubeless compatible
Rear: Race Face ARC Offset 27, 27mm IW, DT Swiss 370, 12x148mm, XD freehub, 28H, 6 bolt, tubeless compatible
Tires Maxxis Rekon Race, EXO 120TPI, 29x2.4
Brakes SRAM Level Bronze 4 Piston
Crankset SRAM GX Eagle, 32T, Boost 148 DUB
Bottom Bracket SRAM DUB, BSA 73mm
Shifters SRAM GX AXS Rocker
Cassette/Freewheel SRAM GX Eagle, 10-52, 12 speed
Rear Derailleur SRAM GX Eagle AXS, 12 speed
Rotors SRAM Centerline 6-Bolt
Headset FSA IS2 1-1/2 x 1-1/2
Brake Levers SRAM Level Bronze Stealth 4 Piston
Handlebars Race Face Turbine Alloy, 35mm clamp, 760mm width, 10mm rise
Chain SRAM GX, 12 speed
Stem Race Face Aeffect Alloy, 35mm clamp, 6 degree
Seatpost Race Face Ride XC Alloy 30.9
Saddle Prologo Dimension NDR T4.0
Pedals Sold Separately

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Five Black / Small 042677623588 0I0FSAGT1ASM 210000037849
Five Black / Medium 042677623571 0I0FSAGT1AMD 210000037850
Five Black / Large 042677623564 0I0FSAGT1ALG 210000037851
Five Black / X-Large 042677623595 0I0FSAGT1AXL 210000037852
